VISCOSE RAYON - MATERIAL SAFETY DATA SHEET
|
SECTION 1 - IDENTIFICATION |
|
|
PRODUCT NAME |
: VISCOSE RAYON |
|
CHEMICAL SYNONYMS |
: (C6H10O6)n n=250~300 |
|
CHEMICAL FAMILY |
: CELLULOSE |
|
SECTION 2 - HAZARDOUS INGREDIENTS |
|
|
HAZARDOUS INGREDIENT |
: BE FREE FROM HAZARD |
|
SECTION 3 - PHYSICAL DATA |
|
|
MELTING POINT |
: NONE (UNMELTED) |
|
BOILING POINT |
: NONE (UNBOILED) |
|
SPECIFIC GRAVITY |
: 1.51 |
|
VAPOR PRESSURE |
: NONE (NONVOLATILE) |
|
VAPOR DENSITY |
: NONE (NONVOLATILE) |
|
SOLUBILITY IN WATER |
: INSOLUBLE IN WATER |
|
PERCENT VOLATILE |
: NONE (NONVOLATILE) |
|
EVAPORATION RATE |
: NONE (NONVOLATILE) |
|
APPEARANCE AND ODOR |
: WHITE FIBRE DRIPPING WITH MOISTURE AND ODORLESS |
|
SECTION 4 - FIRE AND EXPLOSION HAZARD DATA |
|
|
FLASH POINT |
: COLORED & DEGRADED AT 260~300℃ (500~570℉), IGNITED AT 400~470℃ (750~880℉) |
|
EXPLOSIVE LIMIT |
: CAN NOT BE FOUND |
|
EXTINGUISHING MEDIA |
:EQUALLY ORDINARY FIRE EXTINGUISHING METHOD |
|
SPECIAL FIRE FIGHTING PROCEDURE |
: NOTHING TO MENTION SPECIALLY |
|
SECTION 5 - HEALTH HAZARD DATA |
|
|
THRESHOLD LIMIT VALUE |
:NONE |
|
EFECTS OF OVEREXPOSURE |
: NOTHING TO MENTION SPECIALLY |
|
EMERGENCY AND FIRST AID PROCEDURE |
: NONE |
|
SECTION 6 - REACTIVITY DATA |
|
|
STABILITY |
: BE STABLE |
|
HAZARDOUS POLIMERIZATION |
: BE FREE FROM HAZARD |
|
HAZARDOUS DECOMPOSITION PRODUCT |
: BE FREE FROM HAZARD |
|
CONDITIONS TO AVOID |
: NOTHING TO MENTION SPECIALLY |
|
SECTION 7 - SPILL OR LEAK PROCEDURE |
|
|
SPIL OR LEAK PROCEDRE |
: NOTHING TO MENTION SPECIALLY (EQUAL TO PAPER & COTTON) |
|
WASTE DISPOSAL |
: NOTHING TO MENTION SPECIALLY (EQUAL TO PAPER & COTTON) |
|
SECTION 8 - SPECIAL PROTECTION INFORMETION |
|
|
RESPIRATORY PROTECTION |
: USELESS |
|
VENTILATION |
: USELESS |
|
PROTECTIVE GLOVES |
: USELESS |
|
SECTION 9 - SPECIAL PRECAUTOINS |
: NONE |
REGARDING DIA CHIP
Dia chip is an extremely thin scalelike pattern material composed primarily of ceramic raw material.
As a natural characteristic colored inorganic pattern material, according to various image and depending on the mixture of the color and particle it can express effectively the mystic natural rock or marble like quality feeling and heavy rock grain pattern. It create design and function which have not existed before and will extend possibilities into entirely new fields.
FRESH PATTERN EFFECT OF DIA CHIP
|
․Rock grain pattern |
Natural shape and the particle size of Dia chip create heavy rock grain pattern feeling and mystic which have not existed so far and will keep possibilities to develop new materials. |
|
․Natural rock pattern |
Dia chip features mat like coloring and the repeatedly piled pattern feelings within the elementary resin produce natural deep pattern equal to natural rock and enhance high class feelings. |
|
․Granite pattern |
While skillfully expressing the color, design and quality feelings of granite, depending on the mixture it can create freely the pattern feelings which cannot be obtained in natural rocks. |
|
․Marble pattern |
On the base colored pale by coloring agent add Dia Chip matched with the design and can produce natural characteristics of gorgeous heavy marble. |
TYPE CODE, QUALITY SPECIFICATION OF DIA CHIP
|
Spec./Type No. |
DM-2 |
DM-5 |
|
Shape |
Scalelike |
Scalelike |
|
Average particle size |
1mm (16Mesh) |
3mm |
|
Bulk Density |
0.3 |
0.25 |
|
Material |
Ceramic |
Ceramic |
|
Heatresistance |
230℃ |
230℃ |
|
Packing |
10kg Packed in kraft 3ply paper bag |
|
COLOR SHADE
|
1. Yellow |
2. Cream |
3. Beige |
4. Pink |
5. Olive |
6. Green |
|
7. Sky Blue |
8. Blue |
9. Brown |
10. White |
11. Grey |
12. Black |
․Available in 12 abundant colors, however specified colors are producible if order exceed certain quantity. Please consult us.
|
DM-2 type |
This is conspicuous grade and the average particle size is of large 1mm. The pattern clearly rise and is suitable to express color, design and quality feelings of natural rock.
|
|
DM-5 type |
This is the most largest grade and the particle size is coarse of 2mm~3mm. It is finished in dynamically risen pattern and are used in casting, mixing into paper etc. |
FUNCTION, USAGE DEVELOPMENT OF DIA CHIP
Dia Chip present good compatibility with syntetic resins, paints, emulsion binders and adhesive agents and moreover this pattern material features excellent adhesion. It can be used widely for plastics, injection molding, extrusion molding, casting, spray painting, sprinkling and mixing into paper etc.,
|
Function |
Usage |
|
|
․Design Nature ․Pattern Effect ․Coloring Feeling ․Solid Feeling Pattern ․Light Weighted Natural Rock Pattern ․Size Stability |
․Plastic kneaded pattern ․Polyester casting pattern ․BMC, SMC kneaded pattern ․Vinyl chloride tile Vinyl chloride sheet pattern ․Vinyl chloride cloth pattern ․Cast acrylic resin pattern |
․Wall paper, mixing into paper ․Picture patching, sand picture, craft articles ․Christmas decoration ․Water pattern paint ․Outer wall pattern paint ․Flooring material pattern paint |
DIA CHIP APPLICATION EXAMPLES
Plastic kneaded pattern
Prominent especially in thermal stability and provides prominet characters of resistance ot solvents, chemicals, weather and moisture. Because of its natural scalelike shape and mat like hue feeling, it is extensively used as a coloring pattern material for synthetic resin.
Standard adding ratio ․Adding just a small quantity of 0.5%~3% to synthetic resin creates a natural rock grain pattern.
In polyester, acrylic gel coat
In the mixture of transparent gel coat, aluminum hydroxide, glass fibre and other additive add Dia Chip 1%~3% in weight proportion and when molded it will be finished in heavy pattern feeling of natural rock.
|
․Casting |
It is effective as a pattern material for production of small quantity board and block casting products. |
|
․Spray |
When mixed Dia Chip is sprayed on the surface of male type and female type, the pattern film can be finished thin. |
|
․BMC |
Quality stabilized solid pattern effect is obtained and the surface is finished smoothly. |
|
․SMC |
It is useful to lighten the weight of thin formed products and yet it will give heavy pattern feelings. |
Vinyl flooring material (Tile, Linoleum) cloth, board.
According to the usage purpose calculate the mixing proportion of PVC, resin color, plasticizer and stabilizer and by using banbury mixer mix until the resin color disperse completely between each vinyl compound layers.
Method to imporve pattern effect
․When suitable quantity of dia chip is added in transparent resin or in pale milk white colored resin, the marble like pattern will be finished solidly.
․In general when sheet or the molding product thickness is thick the adding ratio is decreased and in case if is thin the adding ratio is increased. Thus the pattern feeling will be more effective.
REGARDING CELL FLAKE
Cell Flake is chemically synthesized composed primarily of cellulose raw material and is entirely new highly fashionable pattern material. It is square, thin with flexibility and though dynamical, has shape of both dignity and grace. It can express spotted pattern easily which are unable by common coloring materials. The novel colors and patterns are good in compatibility with the elementary resin and produce vivid patterns effectively and keep possibilities of creating dreamful designs and fashions headed for future.
FRESH PATTERN EFFECT OF CELL FLAKE
|
․Square shape pattern |
The scattered spotted pattern of thin, flexible square shaped flake rise solidly and display novel design effect. |
|
․Spotted pattern |
Transparent color and pattern materials match well with oher dyeing pigments and express spotted pattern vividly thus serve to develop high added value products. |
|
․Colorful pattern |
Color complying to the image and according to the mixing of various different sizes of particles, unique colorful pattern and uneven feelings are expressed thus create dreamful colors. |
|
․Compound pattern |
Mixing several different colors and when shading is given the repeatedly piled pattern feeling become heavily coloring with solidity and dignity. |
TYPE CODE, SPECIFICATION OF CELL FLAKE
|
Spec./Type No. |
R-20 |
|
Shape |
Random |
|
Particle Size |
1mm x 2mm |
|
Bulk Density |
0.15 |
|
Material |
Cellulose |
|
Heat Resistance |
200℃ |
|
Packing |
5kg Packed in kraft 3ply paper bag |
COLOR SHADE
|
1. Yellow |
2. Beige |
3. Brown |
4. Pink |
5. Olive |
6. Green |
|
7. Sky Blue |
8. Blue |
9. Sepia |
10. Red |
11. Violet |
12. Black |
․Available in 12 abundant colors, however specified colors are producible if order exceed certain quantity. Please consult us.
|
CELL FLAKE R-20 type |
This grade only the shape is random with 1mm~2mm in center and various sizes are mixed giving pattern material a natural effect. The largely risen pattern gives dynamical finish. |
FUNCTION, USAGE DEVOLOPMENT OF CELL FLAKE
|
Fuction |
Usage |
|
|
․Design Nature ․Pattern Effect ․Coloring Effect ․Solid Feeling Pattern ․Light Weighted pattern ․Size stability |
․Thermoplastic resin kneaded pattern ․Polyester casting pattern ․BMC, SMC kneaded pattern ․Vinyl chloride tile Vinyl chloride sheet pattern ․Vinyl chloride cloth pattern ․Acrylic resin casting pattern |
․Wall paper pattern, mixing into paper. ․Picture patching, sand picture, craft article. ․Christmas decoration ․Water pattern paint ․Outer wall pattern paint ․Flooring material pattern paint |
CELL FLAKE APPLICATION EXAMPLES
|
Thermoplastic resin kneaded |
According to the desired pattern feeling add 0.1%~0.5% in PE, PP, GP, AS, ABS, Urethane and other general purpose resins. It can be used with whichever processing Method of dry blend method, dry color method or Masterbatch method. |
|
Vinyl chloride resin kneaded |
Add 0.1%~0.5% in phenol, urea, melamine resin and the pattern effect is obtained. |
|
Polyester gel coat |
Add 0.5%~3% Cell Flake in transparent gel coat, aluminum hydroxide, glass fiber and other additive mixture and stable quality pattern effect can be obtained. ․Casting - It is effective as a pattern material for small quantity production of board and block castign products. ․Spray - When Cell Flake is sprayed on the surface of male type and female type the pattern film will be finished thin. ․BMC - Quality stabilized solid pattern effect is obtained and the surface is finished smoothly. ․SMC - It is useful to lighten the weight of thin formed products and yet it will give heavy pattern feelings. |
|
Water pattern paint |
As a pattern material of emulsion family pattern paint, blend several colors adding 3%~10% and it will be colorful pattern paint with solid feelings. When titanium and pigment quantity is lessened the fog will disappear and can be seen clearly risen. |
|
Mixig into paper |
It is used as a pattern material for papers ranging from mass produced mechanized mixing method to craft paper made by traditional techniques involving a hand mixing method. |
|
Decoration |
Unique decoration can be created by scattering mechanically over handicrafts, paper, woven fabrics etc. Applied with starch glue, emulsion binder. |
